nginx+Jupyter: 用reverse proxying 令notebook server 更安全

Posted on 24 October, 2022

This is originally posted on Medium in 2020. Link to article.

Background from Ben Neale (https://unsplash.com/@ben_neale)

Hi！有用開Jupyter notebook嘅朋友都應該有遇過一個問題：點樣係localhost以外連接到notebook呢？我自己冇耐之前都係用Jupyter notebook內置嘅功能去set up個notebook server，但係咁樣係有缺點嘅，譬如：

要expose一個port出去dedicate比notebook server。同一個network開多過一個notebook server，就要做mapping/forwarding
如果你係用443之外嘅port，打完個網址又要打多個port名。咁做係好煩同容易唔記得
安全考慮上，reverse proxy唔直接expose個server IP出去，亦可以當做應用層面嘅firewall

所以今日就介紹下點樣係前面加個nginx reverse proxy更方便同安全地經 Internet access到notebook server。

準備

首先，你要有張SSL cert–有自己domain可以去letsencrypt攞一張，冇嘅自己self-sign一張亦可。(當然冇咁好啦)

之後就當然要裝nginx啦，假設你係用緊Debian-based distro：

sudo apt-get update; sudo apt-get install -y nginx

安裝完之後，可以check下係唔係正常運作緊：

user@your-os:/etc/nginx$ service nginx status ● nginx.service — A high performance web server and a reverse proxy server Loaded: loaded (/lib/systemd/system/nginx.service; enabled; vendor preset: enabled) Active: active (running) since Fri 2020–03–06 18:33:39 HKT; 5h 19min ago Docs: man:nginx(8) Process: 27169 ExecStop=/sbin/start-stop-daemon — quiet — stop — retry QUIT/5 — pidfile /run/nginx.pid (code=exited, status=0/SUCCESS) Process: 27184 ExecStart=/usr/sbin/nginx -g daemon on; master_process on; (code=exited, status=0/SUCCESS) Process: 27170 ExecStartPre=/usr/sbin/nginx -t -q -g daemon on; master_process on; (code=exited, status=0/SUCCESS) Main PID: 27185 (nginx) Tasks: 7 (limit: 4915) CGroup: /system.slice/nginx.service ├─27185 nginx: master process /usr/sbin/nginx -g daemon on; master_process on; ├─27188 nginx: worker process ├─27190 nginx: worker process ├─27191 nginx: worker process ├─27193 nginx: worker process ├─27194 nginx: worker process └─27195 nginx: worker process

咁就準備好啦。

Set up Reverse Proxy

JupyterHub本身就有doc提供到set up reverse proxy嘅方法：

https://jupyterhub.readthedocs.io/en/stable/reference/config-proxy.html

以下係佢提供，放係 /etc/nginx/sites-enabled 既config，我地可以攞嚟用(=copy&paste):

# top-level http config for websocket headers# If Upgrade is defined, Connection = upgrade# If Upgrade is empty, Connection = closemap $http_upgrade $connection_upgrade { default upgrade; '' close; }# HTTP server to redirect all 80 traffic to SSL/HTTPSserver { listen 80; server_name HUB.DOMAIN.TLD;# Tell all requests to port 80 to be 302 redirected to HTTPSreturn302 https://$host$request_uri; }# HTTPS server to handle JupyterHubserver { listen 443; ssl on; server_name HUB.DOMAIN.TLD; ssl_certificate /etc/letsencrypt/live/HUB.DOMAIN.TLD/fullchain.pem; ssl_certificate_key /etc/letsencrypt/live/HUB.DOMAIN.TLD/privkey.pem; ssl_protocols TLSv1 TLSv1.1 TLSv1.2; ssl_prefer_server_ciphers on; ssl_dhparam /etc/ssl/certs/dhparam.pem; ssl_ciphers 'ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-ECDSA-AES256-GCM-SHA384:DHE-RSA-AES128-GCM-SHA256:DHE-DSS-AES128-GCM-SHA256:kEDH+AESGCM:ECDHE-RSA-AES128-SHA256:ECDHE-ECDSA-AES128-SHA256:ECDHE-RSA-AES128-SHA:ECDHE-ECDSA-AES128-SHA:ECDHE-RSA-AES256-SHA384:ECDHE-ECDSA-AES256-SHA384:ECDHE-RSA-AES256-SHA:ECDHE-ECDSA-AES256-SHA:DHE-RSA-AES128-SHA256:DHE-RSA-AES128-SHA:DHE-DSS-AES128-SHA256:DHE-RSA-AES256-SHA256:DHE-DSS-AES256-SHA:DHE-RSA-AES256-SHA:AES128-GCM-SHA256:AES256-GCM-SHA384:AES128-SHA256:AES256-SHA256:AES128-SHA:AES256-SHA:AES:CAMELLIA:DES-CBC3-SHA:!aNULL:!eNULL:!EXPORT:!DES:!RC4:!MD5:!PSK:!aECDH:!EDH-DSS-DES-CBC3-SHA:!EDH-RSA-DES-CBC3-SHA:!KRB5-DES-CBC3-SHA'; ssl_session_timeout 1d; ssl_session_cache shared:SSL:50m; ssl_stapling on; ssl_stapling_verify on; add_header Strict-Transport-Security max-age=15768000;# Managing literal requests to the JupyterHub front endlocation / { proxy_pass http://127.0.0.1:8000; proxy_set_header X-Real-IP $remote_addr; proxy_set_header Host $host; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;# websocket headersproxy_set_header Upgrade $http_upgrade; proxy_set_header Connection $connection_upgrade; }# Managing requests to verify letsencrypt hostlocation ~ /.well-known { allow all; } }

未set up ssl_dhparam嘅話，可以行呢個command 用幾分鐘嘅時間generate一個新嘅：

openssl dhparam -out /etc/ssl/certs/dhparam.pem 4096

咁當然啦，上邊個snippet凡係有提到HUB.DOMAIN.TLD嘅地方，就要改做你個網址，然後塞埋張SSL cert/chain+private key入去：

server_name HUB.DOMAIN.TLD; . . . ssl_certificate/etc/letsencrypt/live/HUB.DOMAIN.TLD/fullchain.pem; ssl_certificate_key/etc/letsencrypt/live/HUB.DOMAIN.TLD/privkey.pem;

然後proxy_pass入面條URL都要改返notebook server個port(預設係8888)：
